We suggest air or LCL for small orders and container or bulk vessel for large orders. We usually trade in EX-Works, FOB, CFR and CIF. 30% T/T deposit and 70% T/T balance before shipment or 100% L/C at sight.
Saving on the Land space of the construction site allocated for the installation of concrete batching plant.
The cost of the skip hoist batching plant is much less than the cost of the conveyor belt batching plant
This feature allows skip hoist concrete plants to take the place of one of the modern standards for concrete production.
Very suitable for small engineering projects, easy to operate and maintain, reduced labor
Maximum productivity (m3/h)
Discharging height (m)
Working cycle time(s)
Total power (kw)
Aggregate weighing accuracy
Cement weighing accuracy
Water weighing accuracy
Additive weighing accuracy
*The actual configuration is subject to the contract subject, the pictures and videos are for reference only*
●Operation Recycle Time(S):72
●Dimension Transport State(mm):3050*2530*2680
●Dimension Work State(mm):4461*3050*4180
●Mixing Blade Rotate Speed:35r/min
●Mixing Blade Number:2x7
●Water Pump Motor Model:BL12_12_1.1
●Water Pump Motor Power:1.1kw
●accumulated weighing hoppers:2
●Volume of Weighing hopper:800L
●Maximum weighing magnitude:1500kg
●Kindsof batching aggregate:2
●Transition belt speed:1m/s
●The bunker body is made of ST-37 A1 quality 5 mm sheet metal, its top is reinforced to prevent abrasion.
●Cement Weighing Capacity:500kg
●Cement Weighing Load cells:3units500kg
●Water Weighing Capacity:300kg
●Water Weighing Load cells:3units500kg
●Additive Weighing Capacity:30L
●Additive Weighing Load cells:1unit50kg
●Volume:OPTIONAL(made bolte dorwelded)
●Silo’s protection flap:Patterned skid plate
●Level indicators:2pcs.each（two point）
●Feet:NPU 260 profile In each silo 3 pieces Plasticizer jet
●Inverter Air Conditioner
●Mix control terminal
●Input power 380/440 +/- 5%
●Output power 220 and 24 volts
●Automatic control unit
